DIN 2393 precision welded steel tubes tau txais ntau yam kev ua thiab kev kho cua sov, xws li kev tshem tawm sab hauv thiab sab nraud, annealing thiab pickling, txias dov, ci annealing, thiab lwm yam.
DIN 2393 qhia txog txoj kev kos npe ntawm cov raj steel, uas feem ntau suav nrog cov ntaub ntawv xws li cov khoom siv, kev xa khoom, txoj kab uas hla, sab hauv, thiab lwm yam. Piv txwv li, DIN 2393 - St 52-3 BK 18 × ID 13, cov khoom siv yog St 52-3, txoj kev xa khoom yog BK (ci kos), lub taub sab nraud yog 18mm, thiab sab hauv txoj kab uas hla yog 13mm.
DIN 2393 precision steel raj yog dav siv nyob rau hauv lub teb ntawm tsheb, hnub ci zog, hlau khoom, structural yeeb nkab ua, thiab lwm yam vim lawv high precision thiab zoo mechanical zog.
Cov ntaub ntawv khoom
Tshuaj muaj pes tsawg leeg ntawm DIN 2393 Bright Precision Welded Steel Tube
|
QIB |
C max |
Si max |
Mn min |
P max |
S max |
Ni |
Cr |
|
qib 52.3 |
0.22 |
0.55Max |
1.60 Min |
0.040 |
0.040 |
||
|
St 28 |
0.13 |
0.50 |
0.50 |
||||
|
Qhov 34.2 |
0.15 |
0.50 |
0.50 |
||||
|
Qhov 37.2 |
0.17 |
0.50 |
0.50 |
||||
|
Qhov 44.2 |
0.21 |
0.50 |
0.50 |
Khoom siv: St28, St34.2, St37.2, St44.2, St52.3
Nto: Polished, brightness, xim hlau
Loj: OD 6mm -65mm, WT 1-8mm
Ntev: Random 10-6000mm, kev cai ua ib yam
kam rau ua: +/-0.05mm.special kam rau ua: +/-0.03mm
Cov khoom tso tawm
DIN 2393 ERW Cold-Drawn Precision Tubes
Vim li cas thiaj xaiv GNEE
GNEE muaj ISO9001-2000 kev tswj hwm zoo thiab ISO14001 kev tiv thaiv ib puag ncig.
Nws raug xa tawm mus rau ntau tshaj 60 lub teb chaws thiab cheeb tsam suav nrog Russia, Canada, Is Nrias teb, Brazil, Southeast Asia, thiab lwm yam.
Lub tuam txhab tam sim no muaj ntau dua 30, 000 tons ntawm cov khoom muag, nrog ntau ntau yam rau koj xaiv! GB, ASTM, JIS, DIN thiab lwm yam qauv tuaj yeem siv tau.
