Lub ntsiab alloy Cheebtsam ntawm A335 P92 boiler raj yog Cr: 9%, Mo: 1%, thiab lwm yam lub caij, thiab ntxiv ib qho nyiaj ntawm W, uas nce qhov sib npaug molybdenum (Mo+0.5W) ntawm cov khoom los ntawm 1% ntawm P91 steel mus txog 1.5%. Kev kub siab lub zog thiab creep zog yog txhim kho. Qhov no ua rau nws siv tau rau hauv cov chav ultra-supercritical thiab ib puag ncig siab tshaj 600 degrees Celsius.
A335 P92 high-pressure boiler raj yog tsim rau khoov, curling thiab zoo sib xws txheej txheem raws li fusion vuam, thiab xaiv tau raws li tus tsim, ua hauj lwm tej yam kev mob, mechanical zog thiab kub yam ntxwv.
Cov ntaub ntawv khoom
Chemical Composition (%) ntawm ASTM A335 P92 Seamless Boiler Tubes
| Chemical Composition (wt%) | Yam tsawg kawg nkaus | Qhov siab tshaj plaws |
|---|---|---|
| Cov pa roj carbon (C) | 0.07 | 0.13 |
| Silicon (Si) | - | 0.50 |
| Manganese (Mn) | 0.30 | 0.60 |
| Phosphorus (P) | 0.002 | 0.020 |
| Sulfur (S) | 0.001 | 0.010 |
| Chromium (Cr) | 8.50 | 9.50 |
| Molybdenum (hli) | 0.30 | 0.60 |
| Nickel (Ni) | - | 0.40 |
| Vanadium (V) | 0.15 | 0.25 |
| Nitrogen (N) | 0.03 | 0.07 |
| Titanium (Ti) | - | 0.01 |
| Tungsten (W) | 1.50 | 2.00 |
| Zirconium (Zr) | - | 0.01 |
| Boron (B) | 0.001 | 0.006 |
| Aluminium (Al) | - | 0.02 |
| Niobium (Nb) | 0.04 | 0.09 |
Mechanical zog ntawm ASTM A335 P92 Alloy Steel Seamless Boiler Tube
| Cov khoom | Cov ntaub ntawv |
| Tensile zog, min, (MPa) | 620 |
| Yield zog, min, (MPa) | 440 |
| Elongation, min, (%), L / T | 20/... |
1.Manufacture method: txias dov, txias drawn, kub dov.
2. Txuj: ASTM A335
2. Qib: P92
3.Size: 12.7mm * 1.2mm - 325mm * 50mm
4.Length: 16000mm max, ib zaug lossis ob zaug random
Cov khoom tso tawm
ASTM A335 P92 kub resistant alloy yeeb nkab
Vim li cas thiaj xaiv GNEE
A335 P92 boiler raj tsim los ntawm GNEE ua raws li cov qauv kev ua haujlwm ntawm ASTMA335/A335MASTMA213/213M thiab yog tsim los ntawm kub dov thiab forging, uas yog yooj yim rau ntau yam kev khiav hauj lwm thaum lub sij hawm tsim thiab installation.
A335 P92 boiler raj kuj muaj ntau yam kev xaiv hauv cov lus qhia tshwj xeeb thiab qhov ntau thiab tsawg, uas tuaj yeem hloov kho raws li cov kev xav tau tshwj xeeb ntawm cov neeg siv khoom. Piv txwv li, nws txoj kab uas hla sab nraud tuaj yeem nyob ntawm 57mm txog 762mm, thiab phab ntsa tuab yog li ntawm 5.0mm txog 130mm.
GNEE tseem muab ASTM A335 P92 cov raj kub kub hauv daim ntawv ntawm cov raj puag ncig, cov raj square, cov duab plaub thiab cov raj hydraulic.
Yog tias koj tab tom nrhiav rau cov yeeb nkab steel, thov hu rau peb hauv lub sijhawm kom tau txais nqe lus!sales@gneetube.com
GNEE CUSTOMER VAJTSWV
GNEE Factory Environment
GNEE packaging thiab Shipping
FAQ
Q: Koj puas muaj kev tswj xyuas zoo?
A: Yog lawm, peb muaj peb tus kheej lub chaw soj nstuam zoo. Peb tog kuaj kev pabcuam kuj muaj.
Q: Koj muab kev pabcuam dab tsi?
A: Kev pabcuam customized rau txhua tus neeg siv khoom, thov hu rau peb!
Q. Koj lub sijhawm ua haujlwm yog dab tsi?
A. Cov Tshuag tsis tu ncua feem ntau yog 10 hnub. Nyob ntawm cov khoom.
