ASTM A{0}} alloy steel yeeb nkabyog cov yeeb nkab zoo seamless steel ua los ntawm cov pa roj carbon zoo, cov hlau tsis tshua muaj hlau lossis stainless hlau ua raws li tus qauv ASTM A334. Cov yeeb nkab steel no muaj kev tiv thaiv zoo heev thiab cov khoom siv kho tshuab, ua rau nws siv dav hauv roj av, tshuaj lom neeg kev lag luam, hluav taws xob, nkoj tsim, aviation thiab lwm yam kev lag luam.
ASTM A334 Qib 6 steel yeeb nkab muaj ib txoj kab uas hla sab nraud tsawg dua 1 ⁄ 2 nyob rau hauv. [12.7 mm], seamless thiab welded carbon thiab alloy steel yeeb nkab, haum rau siv nyob rau hauv qis kub. Cov kav dej yuav tsum tau tsim los siv cov txheej txheem vuam seamless lossis automated vuam uas tsis muaj cov hlau muab tub lim ntxiv thaum lub sijhawm ua haujlwm vuam.
ASME SA334 Qib 6 Carbon Steel Seamless Yeeb Nkab yog cov yeeb nkab nruab nrab carbon steel nrog cov ntsiab lus siab tshaj plaws ntawm 0.30 % thiab manganese cov ntsiab lus ntawm 0.29 - 1.06%. ASME SA 333 Qib 6 yeeb nkab yog ductile thiab muaj zog nrog cov yam ntxwv coj mus ntev.
Tshuaj muaj pes tsawg leeg
| Element | Kev sib xyaw,% |
| Qib 6 A | |
| Cov pa roj carbon, max | 0.30 |
| Manganese | 0.29–1.06 |
| Phosphorus, max | 0.025 |
| Sulfur, max | 0.025 |
| Silicon | 0.10 min |
| Nickel | … |
| Chromium | … |
| Tooj | … |
| Cobalt | … |
| Molybdenum | … |
A Rau txhua qhov txo qis ntawm {{0}}}01% carbon qis dua 0.30%, qhov nce ntawm 0.05% manganese saum 1.06% yuav tso cai rau ntau tshaj 1.35% manganese.
Mechanical Properties
| Qib 6 | ||
| ksi ua | MPa | |
| Tensile zog, min | 60 | 415 |
| Yield zog, min | 35 | 240 |
| Rockwell | B 90 | |
| Brinell | 190 | |
Cov cuab yeej cuab tam yuav tsum tsis txhob siv rau tubing me dua 1 ⁄ 8 nyob rau hauv. [3.2 mm] nyob rau hauv sab nraud txoj kab uas hla thiab nrog ib tug phab ntsa thickness nyob rau hauv 0.015 nyob rau hauv.[0.4 mm].
ASTM A334 GR 6 steel yeeb nkab
Kev qhia tshwj xeeb: ASTM A334, ASME SA 334
Qhov Loj: 4 "NB txog 26" NB
Phab ntsa Thickness:2.0mm-14 mm
Teem sijhawm: 20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH & hnyav dua
Hom: Seamless / Welded / Tsawg Kub
Ntev: 5800mm; 6000mm; 6 096mm; 7 315mm; 11800mm; thiab lwm yam.
Qib: Qib 6
GNEE A334 steel yeeb nkab txheej txheem
a: normalizing los ntawm cua sov mus rau ib tug zoo kub tsis tsawg tshaj li 1550 degree F [845 degree] thiab txias nyob rau hauv cov huab cua los yog nyob rau hauv lub txias chamber ntawm ib tug huab cua-tswj rauv.
b: Rov ua kom sov thiab tswj cov kev ua haujlwm kub thiab kub ua kom tiav kom tiav qhov kub ntawm 1550 txog 1750 degree F [845 txog 955 degree] thiab txias hauv qhov cua sov cua sov los ntawm qhov pib kub tsis pub tsawg tshaj 1550 degree F [845 degree] .
Kev tshuaj xyuas thiab kev sim: tshuaj lom neeg muaj pes tsawg leeg, kev sim tensile, kev sim flattening, flaring test, hardness test, impact test, non-destructive testing, surface inspection, dimensional inspection.
