EN 10297-1 yog tus qauv European rau seamless steel raj rau kev siv tshuab thiab kev tsim vaj tsev dav dav.
Lub C45E steel raj muab los ntawm GNEE yog lub zog nruab nrab carbon steel nkag rau hauv forged lossis normalized mob. Lub zog tensile ntawm C45E carbon steel raj yog nruab nrab ntawm 570 thiab 700 MPa, thiab Brinell hardness range yog 170-210HB. Nws muaj lub zog zoo, toughness, hnav tsis kam thiab cuam tshuam tsis kam.
EN 10297-1 C45E structural seamless raj yog siv dav hauv kev tsim cov khoom siv kho tshuab xws li shafts, bolts, txuas rods, studs, plungers, pins, rollers, spindles, ratchets, crankshafts, torsion bars, tes tsho, worms, teeb gears, guide rods, thiab lwm yam.
Cov ntaub ntawv khoom
EN 10297-1 C45E seamless steel kav dej tshuaj muaj pes tsawg leeg (%)
| C |
Si |
Mn |
Ni |
P |
S |
Cr |
Mo |
|
0.42 - 0.50 |
max 0.4 |
0.5 - 0.8 |
max 0.4 |
max 0.03 |
max 0.035 |
max 0.4 |
max 0.1 |
EN 10297-1 C45E seamless steel kav cov cuab yeej cuab tam:
| Qib Steel |
Yield zog (ReH) Mpa |
Tensile zog (Rm) Mpa |
Elongation A% |
|||||||||
|
Phab ntsa thickness rau T hauv mm |
Phab ntsa thickness rau T hauv mm |
Tsawg dua los yog sib npaug li 16 |
＞ 16 Tsawg dua lossis sib npaug rau 40 |
40 Tsawg dua los yog sib npaug rau 80 |
||||||||
|
Tsawg dua los yog sib npaug li 16 |
＞16 |
＞40 |
Tsawg dua los yog sib npaug li 16 |
＞16 |
＞40 |
|||||||
|
l |
t |
l |
t |
l |
t |
|||||||
|
C45E |
340 |
305 |
305 |
620 |
580 |
580 |
14 |
12 |
16 |
14 |
16 |
14 |
Cov khoom tso tawm
EN 10297-1 Carbon Steel Seamless Circular Steel Tubes
