19Mn5 alloy steel yeeb nkab feem ntau yog siv los tsim cov kav dej rau cov cua sov accumulators. Nws kuj tseem tsim nyog rau kev tsim cov hlau phaj rau cov boiler loj drums thiab cov hlab ntsha siab thiab lwm yam khoom siv, nrog rau boiler steel kav nrog phab ntsa kub tsawg dua los yog sib npaug li 520 degree. Tsis tas li ntawd, nws tseem tuaj yeem siv los tsim cov chav boilers, cov kav dej, cov hlab ntsha siab thiab cov cuab yeej ntsuas kub txog li 600 degree.
Kev kho cua sov ntawm 19Mn5 seamless steel yeeb nkab suav nrog normalizing thiab quenching thiab tempering. Lub normalizing kub feem ntau yog nyob nruab nrab ntawm 880-910 degree, thaum lub quenching thiab tempering yuav muaj xws li cov kauj ruam xws li quenching thiab tempering.
Cov ntaub ntawv khoom
Tshuaj muaj pes tsawg leeg ntawm DIN 17175 19Mn5 steel kav
|
Qib |
Chemical Composition (%) | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| C | Si | Mn | P | S | Ni | Cr | Mo | Lwm tus | |
| 19mn 5 | 0.17~0.22 | 0.30~0.60 | 1.00~1.30 | 0.040Max | 0.040Max | - | 0.30Max | - | - |
Mechanical zog ntawm DIN 17175 19Mn5 seamless alloy kav
|
Qib |
Khoom siv Tus lej |
MPa los yog N / mm2 | ||
|---|---|---|---|---|
| Min Yield Point |
Tensile zog |
|||
| WT: 16mm Max | WT: 16- 40mm | |||
| 19mn 5 | 1.0482 | - | 315 | 510~610 |
OD: 48mm -720mm
WT: 4mm -58mm
Ntev: 5-12m lossis raws li xav tau
Nto: Varnish / Roj (liab & dub) pleev xim, Zinc coated (kub dipped galvanized), Anti-corrosion hmoov txheej, 2PP / 2PE, 3PP / 3PE, FBE.
Lub xeev xa khoom: Kub Rolled, Cold Drawn
